14 drop 2 voicings of Bb7 — Bb, D, F and Ab, on 3 string sets, in 4 inversions.
What a drop 2 is. A close-position chord with the second voice from the top lowered an octave. Sits on four adjacent strings.
| Shape | String set | Inversion | Position | Difficulty |
|---|---|---|---|---|
| 1101xx | strings 6–5–4–3 | 2nd inversion — F in the bass, the 5th | open position | easy |
| x1313x | strings 5–4–3–2 | Root position — Bb in the bass, the root | open position | easy |
| xx3334 | strings 4–3–2–1 | 2nd inversion — F in the bass, the 5th | around fret 3 | easy |
| 4533xx | strings 6–5–4–3 | 3rd inversion — Ab in the bass, the 7th | around fret 3 | easy |
| xx6766 | strings 4–3–2–1 | 3rd inversion — Ab in the bass, the 7th | around fret 6 | easy |
| 6867xx | strings 6–5–4–3 | Root position — Bb in the bass, the root | around fret 6 | easy |
| x8879x | strings 5–4–3–2 | 2nd inversion — F in the bass, the 5th | around fret 7 | easy |
| x-x-8-10-9-10 | strings 4–3–2–1 | Root position — Bb in the bass, the root | around fret 8 | easy |
| x-11-12-10-11-x | strings 5–4–3–2 | 3rd inversion — Ab in the bass, the 7th | around fret 10 | easy |
| x-x-12-13-11-13 | strings 4–3–2–1 | 1st inversion — D in the bass, the 3rd | around fret 11 | easy |
| 13-13-12-13-x-x | strings 6–5–4–3 | 2nd inversion — F in the bass, the 5th | around fret 12 | easy |
| x-13-15-13-15-x | strings 5–4–3–2 | Root position — Bb in the bass, the root | around fret 13 | easy |
| x5636x | strings 5–4–3–2 | 1st inversion — D in the bass, the 3rd | around fret 3 | moderate |
| 10-11-8-10-x-x | strings 6–5–4–3 | 1st inversion — D in the bass, the 3rd | around fret 8 | moderate |
Shapes are written lowest string first, so x is a string you do not play. To hear these, play them, or see them against the chord’s other shapes, open the Bb7 chord page.
